Item
|
Value
|
|
| Operating speed | 0.1mm~1m/s (Related with actuator forms) | |
| Operating Frequency | Mechanical 60 cycles/min;Electrical 25ccles/min | |
| Insulation resistance | ≥100MΩ (500VDC) | |
| Contact resistance | ≤30MΩ (Initial value) | |
| Test voltage | between terminals of the same polarity | AC1000V, 50/60Hz, 1min |
| Between current-carryingmetal parts and ground (case), and between each terminal and non-current -carrying metal parts. | AC3750V, 50/60Hz, 1min | |
| Vibration resistance | 10 ~55Hz, 1.5mm Double amplitude | |
| Shock resistance |
Destruction: |
|
| Life expectancy |
Mechanical ≥2,000,000 cycles Electrical ≥50,000 cycles |
|
| Weight | Approx. 6.2g (No lever) | |
| Safety approvals | UL/CUL/VDE/TUV/SEMKO/DEMKO/NEMKO/FIMKO/CE/EK/CQC | |
