| Item | Rated voltage | Rated breaking capacity | Standard specifications | Class |
|
NGTS50 Semiconductor Protection |
500V AC/DC |
120kA AC, 50kA DC |
IEC60269-4-1 EN60269-4-1 |
aR/gRC/gRB |
|
NGTS70 Semiconductor Protection |
700V AC/DC |
120kA AC, 50kA DC |
IEC60269-4-1 EN60269-4-1 |
aR/gRC/gRB/gPV |
|
NGTS130 Semiconductor Protection |
1300V AC/DC |
120kA AC, 50kA DC |
IEC60269-4-1 EN60269-4-1 |
aR/gRC/gRB/gPV |
| Item | In(A) |
Order No. |
| NGTS-50 Fuse-link 500V | ||
|
NGTS-50 |
35 | 8600035 |
| 40 | 8600040 | |
| 50 | 8600050 | |
| 60 | 8600060 | |
| 70 | 8600070 | |
| 80 | 8600080 | |
| 90 | 8600090 | |
| 100 | 8600100 | |
| 125 | 8601125 | |
| 150 | 8601150 | |
| 175 | 8601175 | |
| 200 | 8601200 | |
| 225 | 8602225 | |
| 275 | 8602275 | |
| 300 | 8602300 | |
| 350 | 8602350 | |
| 400 | 8602400 | |
| 450 | 8603450 | |
| 500 | 8603500 | |
| 600 | 8603600 | |
| 700 | 8604700 | |
| 800 | 8604800 | |
| 900 | 8605900 | |
| 1000 | 8605100 | |
| 1200 | 8605120 | |
| NGTS-70 Fuse-link 700V | ||
|
NGTS-70 |
35 | 8610035 |
| 40 | 8610040 | |
| 50 | 8610050 | |
| 60 | 8610060 | |
| 70 | 8610070 | |
| 80 | 8610080 | |
| 90 | 8610090 | |
| 100 | 8610100 | |
| 125 | 8611125 | |
| 150 | 8611150 | |
| 175 | 8611175 | |
| 200 | 8611200 | |
| 225 | 8612225 | |
| 250 | 8612250 | |
| 300 | 8612300 | |
| 350 | 8612350 | |
| 400 | 8612400 | |
| 450 | 8613450 | |
| 500 | 8613500 | |
| 600 | 8613600 | |
| 700 | 8614700 | |
| 800 | 8614800 | |
| 1000 | 8614100 | |
| NGTS-130 Fuse-link 1300V | ||
|
NGTS-130 |
63 | 8620063 |
| 80 | 8620080 | |
| 100 | 8620100 | |
| 125 | 8621125 | |
| 150 | 8621150 | |
| 175 | 8621175 | |
| 200 | 8621200 | |
| 225 | 8622225 | |
| 275 | 8622275 | |
| 300 | 8622300 | |
| 350 | 8622350 | |
| 400 | 8622400 | |
| 450 | 8623450 | |
| 500 | 8623500 | |
| 600 | 8623600 | |
| 700 | 8624700 | |
| 900 | 8624900 | |
| 1000 | 8624100 | |
