| Detected Distance Sn | 5mm | 8mm | 5mm | 8mm | ||
| Setting Distance Sn | 0-1.6mm | 0-6.4mm | 0-4mm | 0-6.4mm | ||
| Standard Detected Object A3 Steel | 24×24×1mm³ | 24×24×1mm³ | 24×24×1mm³ | 24×24×1mm³ | ||
| Installation Mode | Flush type | Not flush type | Flush type | Not flush type | ||
| DC power | NPN | NO | JM18L-F5NK | JM18L-Y8NK | JM18L-F5NKE | JM18L-Y8NKE |
| NC | JM18L-F5NB | JM18L-Y8NB | JM18L-F5NBE | JM18L-Y8NBE | ||
| NO/NC | JM18L-F5NH | JM18L-Y8NH | JM18L-F5NHE | JM18L-Y8NHE | ||
| PNP | NO | JM18L-F5PK | JM18L-Y8PK | JM18L-F5PKE | JM18L-Y8PKE | |
| NC | JM18L-F5PB | JM18L-Y8PB | JM18L-F5PBE | JM18L-Y8PBE | ||
| NO/NC | JM18L-F5PH | JM18L-Y8PH | JM18L-F5PHE | JM18L-Y8PHE | ||
| Two-wire system NO | JM18L-F5TK | JM18L-Y8TK | JM18L-F5TKE | JM18L-Y8TKE | ||
| Two-wire system NC | JM18L-F5TB | JM18L-Y8TB | JM18L-F5TBE | JM18L-Y8TBE | ||
| AC power | Two-wire system NO | JM18L-F5AK | JM18L-Y8AK | JM18L-F5AKE | JM18L-Y8AKE | |
| Two-wire system NC | JM18L-F5AB | JM18L-Y8AB | JM18L-F5ABE | JM18L-Y8ABE | ||
| Three-wire system NO/NC | ||||||
| Supply voltage | DC10-30V, AC90-250V | |||||
| Current consumption | NPN/PNP Transistor 10...15mA, DC two-wire ≤ 0.8mA, AC ≤ 2mA | |||||
| Output current | NPN/PNP Transistor ≤ 200mA, DC two-wire 60...80mA, AC ≤ 300mA | |||||
| Output voltage drop | NPN/PNP Transistor ≤ 1.5V, DC two-wire ≤ 7V, AC ≤ 8V | |||||
| Response frequency | NPN/PNP Transistor 400...800Hz, DC two-wire 200Hz, AC 10...20Hz | |||||
| Detected objection | Metal | |||||
| Housing material | ABS Resin/Metal | |||||
| Ambient temperature | -25~70℃ | |||||
| Insulation resistance | ≥ 30MΩ above | |||||
| Protection degree | IP67 | |||||
