| Detected Distance Sn | 10mm | 15mm | 5mm | 15mm | ||
| Setting Distance Sn | 0-8mm | 0-12mm | 0-4mm | 0-12mm | ||
| Standard Detected Object A3 Steel | 45×45×1mm³ | 45×45×1mm³ | 24×24×mm³ | 45×45×1mm³ | ||
| Installation Mode | Flush type | Not flush type | Flush type | Not flush type | ||
| DC power | NPN | NO | JM30L-F10NK | JM30L-Y15NK | JM30L-F10NKE | JM30L-Y15NKE |
| NC | JM30L-F10NB | JM30L-Y15NB | JM30L-F10NBE | JM30L-Y15NBE | ||
| NO/NC | JM30L-F10NH | JM30L-Y15NH | JM30L-F10NHE | JM30L-Y15NHE | ||
| PNP | NO | JM30L-F10PK | JM30L-Y15PK | JM30L-F10PKE | JM30L-Y15PKE | |
| NC | JM30L-F10PB | JM30L-Y15PB | JM30L-F10PBE | JM30L-Y15PBE | ||
| NO/NC | JM30L-F10PH | JM30L-Y15PH | JM30L-F10PHE | JM30L-Y15PHE | ||
| Two-wire system NO | JM30L-F10TK | JM30L-Y15TK | JM30L-F10TKE | JM30L-Y15TKE | ||
| Two-wire system NC | JM30L-F10TB | JM30L-Y15TB | JM30L-F10TBE | JM30L-Y15TBE | ||
| AC power | Two-wire system NO | JM30L-F10AK | JM30L-Y15AK | JM30L-F10AKE | JM30L-Y15AKE | |
| Two-wire system NC | JM30L-F10AB | JM30L-Y15AB | JM30L-F10ABE | JM30L-Y15ABE | ||
| Three-wire system NO/NC | ||||||
| Supply voltage | DC10-30V, AC90-250V | |||||
| Current consumption | NPN/PNP Transistor 10...15mA, DC two-wire ≤ 0.8mA, AC ≤ 2mA | |||||
| Output current | NPN/PNP Transistor ≤ 200mA, DC two-wire 60...80mA, AC ≤ 300mA | |||||
| Output voltage drop | NPN/PNP Transistor ≤ 1.5V, DC two-wire ≤ 7V, AC ≤ 8V | |||||
| Response frequency | NPN/PNP Transistor 400...800Hz, DC two-wire 200Hz, AC 10...20Hz | |||||
| Detected objection | Metal | |||||
| Housing material | ABS Resin/Metal | |||||
| Ambient temperature | -25~70℃ | |||||
| Insulation resistance | ≥ 30MΩ above | |||||
| Protection degree | IP67 | |||||
